I2C Stepper Controller with Integrated Feedback

Cyclops Stepper wraps a DRV8825, WCH CH32V006, and an onboard AS5600 into a 42x42mm board with JST headers and configurable microstepping.

rmingonrmingon
Following
Liked Like project

Just one more thing

To make the experience fit your profile, pick a username and tell us what interests you.

Pick an awesome username
hackaday.io/
Your profile's URL: hackaday.io/username. Max 25 alphanumeric characters.
Pick a few interests
Projects that share your interests
People that share your interests

We found and based on your interests.

Choose more interests.

OK, I'm done! Skip
Public Chat
Similar projects worth following
0 comments
1 followers
  • Description
  • Details
  • Files 0
  • Components 0
  • Logs 0
  • Instructions 0
  • Discussion 0
View Gallery
Public Chat
Core: CH32V006 (3.3 V) driving DRV8825 STEP/DIR and microstep jumpers (JP11/14/17). RV5 sets motor current.
Feedback: AS5600 on the bottom center for a shaft magnet (2–3 mm gap). MCU uses a dedicated, bit-banged I2C master bus to read angle and direction.
Host interface: I2C slave on SDA/SCL (J2). Utility 3-pin header (J1) for 3.3 V, PD1/UART, and GND.
Power: AMS1117-3.3 from VMOT. J2 brings in +12V (12–24 V intended) and GND; logic stays at 3.3 V.
Motor: JST-XH 4-pin (J5) for the two coils from the DRV8825. One coil on pins 1–2, the other on 3–4.
Layout: Four M3 mounting holes, top-side driver and MCU, bottom-side encoder. 3D renders included.
