Any (Particularly Microchip friendly) code to drive the pain in the ass SPI bus on this thing would be greatly appreciated. I've found some examples already that reassure me that my logic and general understanding of how to configure this chip are OK but man am I struggling to actually write to and read back from the shadow register (0)

Hello,

I cant find any files. Can you upload it please?

Thank you,

BR Pavel

I also would like some sauce.

hi, I am trying to use this ic with microprocessor. But i didn't find any information about OTP mode. At OTP mode, is supposed to operating 5.6V, my microcontroller operate with 3.3V  then i don't know  what will be the voltage of 10( SSI_SCL_SPI_CLK), 11(SSI_NSL_SPI_DI) , 12(SSI_DO_SPI_DO),21(SSI_SPI_SEL) at OTP mode. This mode can damage my processor, Do you have any idea ?

At datasheet of AEAT-8800-Q24 says An internal voltage regulator allows the AEAT-8800-Q24 to operate at either 3.3V or 5V supplies. If this encoder operate lower voltage than 3.3V at inside, Will not give more than 3.3v to its output?  I'm talking for otp mode.

OTP mode it's only for reprogram the sensor.

In normal conditions everything is at 3.3V.

On the other hand, if you want to program the sensor because you want it to start in certain mode or with different parameters, then, you have to put 5.6V in the VDD pin of the sensor, but the rest should be 3.3V

it SHOULD be a case of just supplying 5v6 to the power rail, don't think that in this case it will output a higher voltage on your interfacing pins, but it's definitely an important consideration. My understanding is that this particular chip is built for this purpose so you'll be fine (My SPI bus is still wiggling and the picoscope attached to it hasn't gone bang yet)
